| Sunbond ® can now provide UV Curing, UV and/or Thermal Curing, Thermal Curing adhesive, for semiconductor packaging, photon assembly, display , electron parts assembly and many other demanding applications.. |
|
|
| Low Shrankage, Active Alignment Adhesives |
|
Product |
Type |
Color |
Viscosity @mPa |
CTE @ below Tg |
Hardness , Share D |
SB 8410-3L |
UV and /or thermal, Epoxy base |
White |
100000 |
16 |
95 |
SB 9451-100K |
UV and /or thermal, Epoxy Base |
White |
120000 |
14 |
93 |
SB 9857 |
UV and /or thermal ,Acrylac Epoxy base |
Black |
120000 |
25 |
92 |
SB 9028 |
UV and /or thermal, Epoxy Base |
Gray |
100000 |
14 |
94 |
SB 8207W |
UV and /or thermal, Epoxy Base |
White |
8000 |
24 |
90 |
|
|
| Optical Clear, Photonic Adhesives |
|
Product |
Type |
Color |
Viscosity @mPa |
Hardness |
Operating Temperture |
SB 9422-HMW |
UV and /or thermal, Epoxy base |
Clear |
500 |
90D |
-40°C~120°C |
SB 9422-HM-10K |
UV and /or thermal, Epoxy Base |
Clear |
10000 |
92D |
-40°C~120°C |
SB 8307FS-HM-3 |
UV and /or thermal, Epoxy Base |
Clear |
2500 |
75D |
-40°C~120°C |
SB 82231 |
UV Acrylic ,Clear and Soft |
Clear |
500 |
60A |
-40°C~120°C |
SB 82708 |
UV Acrylic, Low refractive index |
Clear |
700 |
50D |
-40°C~120°C |
|
|
| Fast Cure and Good Adhesives |
|
Product |
Type |
Color |
Viscosity @mPa |
Hardness, Share D |
Operating Temperture |
SB 8820 |
Suitable for designing optical products |
Clear |
3000 |
60 |
-40°C~120°C |
SB 8817-B |
Suitable for designing optical products |
Clear |
8500 |
50 |
-40°C~120°C |
SB 9278-HV |
Suitable for bonding glass and Metal |
Clear |
8000 |
75 |
-40°C~120°C |
SB 8820-T |
Thixotropy, Mid viscosity,Suitable for bonding
optical components and various plastics |
Clear |
10000 |
65 |
-40°C~120°C |
|
| |
|
| One compoment Thermal Curebale Epoxy |
|
Product |
Type |
Color |
Viscosity @mPa |
CTE @ below Tg |
Hardness |
SB 2007-B |
Good adhesion to various materials |
Black |
25000 |
55 |
80D |
SB 2011-D |
Good adhesion, low temperature curing |
Black |
45000 |
80 |
66D |
SB 2015-D |
Good test, strong adhesion |
Black |
20000 |
42 |
80D |
SB 2016-DC |
Soft and used for filling |
Translucent |
30000 |
140 |
50A |
SB 2017-D |
High viscosity and low stress |
Black |
160000 |
18 |
62D |
|
|
|
|
|
|
|
SunBond Chemical LLC |
 |
|
|
|
|
![]() |
